IR Flock Sheet
The infrared market has seen a rapid increase in demand in recent years, including proximity sensors for automated driving and face recognition for smartphones. Our IR Flock Sheet was developed to answer the increasing R&D demands of the industry. By specially binding carbon atoms into the flocked pile, we succeeded in achieving a high light absorption performance not only in the visible light spectrum, but also in the infrared light spectrum.
Shop Information
MAINLY FOR B2B/R&D USE!
IF YOUR PROJECT DOES NOT INVOLVE INFRARED LIGHT, THEN WE RECOMMEND OUR VL FLOCK SHEET OR MUSOU BLACK FABRIC KIWAMI.
IR Flock Sheet
No Glue
For orders of more than one (20m) roll, please inquire for bulk pricing and availability.
With Glue
Information
Product Specifications
| Name | Available Dimensions | Thickness (mm) | Composition |
| IR Flock Sheet |
950 mm x 20 m 950 mm x ... mm |
0.8 | Rayon-base / rayon-pile |
| Product Name | UV 250nm | VL 500nm | N-IR 950nm | N-IR 1500nm |
| IR Flock Sheet | 99.7% | 99.7% | 99.7% | 99.5% |
Common Applications
- Dark curtain material for near-infrared non-reflective darkroom
- Background curtain for near-infrared photography
- Pseudo-infrared calibration of near-infrared sensor
- Masking of unwanted objects in the proximity sensor test environment
- Anti-reflection measures during near-infrared motion capture
Usage precautions
- As a drawback of the flocking process, little bits of particulates may be generated due to pile-loss, so it may not be suitable in environments where cleanliness is a top priority such as internal parts of precision equipment.
- There is an area of about 20mm on the corners that are non-flocked and has punch holes. This area is excluded from the effective length of the 950mm measurement.
- In the case of wrinkles or creases, indirectly applying steam and brushing with a soft brush may restore its performance.
- Do not leave any heavy objects on the fabric as it will likely result in a drop in light absorption performance.
